Dynamics of Rotors on Hydrodynamic Bearings

R. Eling[1]
[1]Mitsubishi Turbocharger & Engine Europe, Almere, The Netherlands

This study presents a rotordynamic analysis of a rotor on hydrodynamic bearings using COMSOL Multiphysics®. In this paper, the complexity of the model is gradually increased. Starting point of the analysis is the modal analysis of the rotor in free-free conditions. A Reynolds model is set up to predict the film pressure distribution under shaft loading. Due to the cross coupling terms of the ...

Lamb Waves and Dispersion Curves in Plates and It’s Applications in NDE Experiences Using Comsol Multiphysics

P. Gómez, J. P. Fernandez, and P. D. García
Hydro-Geophysics & NDE Modeling Unit
University of Oviedo
Mieres, Spain

In this paper, a model for numerically obtaining lamb wave modes and dispersion curves in plates is presented. It is shown that COMSOL Multiphysics can be employed to simulate the behavior of guided waves in dispersive plates, which is useful for NDE applications. A two dimensional steel plate (4x0.1 meters) is excited with a space-time impact point source. To model the point source, we use ...

Dynamic Structural Modelling of Wind Turbines Using COMSOL Multiphysics

C. Van der Woude, and S. Narasimhan
University of Waterloo, Waterloo, ON, Canada

This paper presents a study of a wind turbine subjected to wind and seismic loading, carried out using COMSOL Multiphysics. The dynamic properties and response of wind turbine structures are of interest, as recent developments in wind energy have led to the design and construction of increasingly large and flexible turbine structures. A typical turbine structure model was created in ...

FEM Simulation for ‘Pulse-Echo’ Performances of an Ultrasound Imaging Linear Probe

L. Spicci[1]
[1]Esaote SpA, Florence, Italy

Pulse-echo FEM simulation is seldom found in literature for ultrasound imaging array probes, since the complete modeling of such device is extremely complicated. Nevertheless, the 2D FEM described in the present work was successful, thanks to the following design procedure (see figure): Two piezoacoustic models were employed, one for transmission of the pressure wave into the acoustic domain, ...

Simulation of Acoustic Energy Harvesting Using Piezoelectric Plates in a Quarter-Wavelength Straight-Tube Resonator

B. Li[1], J.H. You[1]
[1]Southern Methodist University, Dallas, TX, USA

An acoustic energy harvesting mechanism at low frequency (~200 Hz) using lead zirconate titanate (PZT) piezoelectric cantilever plates placed inside a quarter-wavelength straight-tube resonator has been studied using COMSOL Multiphysics 4.3 and compared with experimental data. When the tube resonator is excited by an incident wave at its acoustic eigenfrequency, an amplified acoustic resonant ...

Beam Characteristics of Ultrasonic Transducers for Underwater Marine Use

G. McRobbie[1], P. Marin-Franch[2], and S. Cochrane[1]
[1] University of Paisley
[2] Piezo Composite Transducers, Ltd

This paper illustrates how finite element analysis with COMSOL Multiphysics can be used to simulate the mechanical and electrical characteristics of piezoelectric transducers. It also shows how beam transmit plots and performance measurements can be modeled by coupling between a piezo domain and a second domain governed by the wave equation.

Numerical Simulation of Phonon Dispersion Relations for Phononic Crystals

G. Zhu[1], E.M. Dede[1]
[1]Toyota Research Institute of North America, Ann Arbor, MI, USA

In previous work, a two-dimensional (2D) model was carried out to simulate the phononic band structure of a phononic crystal with square lattice structure, but this model did not account for the out-of-plane phonon dispersions [1]. In fact, for 2D films used for coating materials, it is more interesting to understand their cross-plane properties. In this work, the phonon dispersion relation of 2D ...

Laser-Ultrasonics Wave Generation and Propagation FE Model in Metallic Materials

A. Cavuto[1], G.M. Revel [1], M. Martarelli [2], F. Sopranzetti [2]
[1]Università Politecnica delle Marche, Ancona, Italy
[2]Università e-Campus, Novedrate (CO), Italy

A 2D axisymmetric model was considered in order to evaluate the propagation paths of the ultrasonic waves generated inside an aluminum plate sample due to a rapid thermal expansion produced by laser pulse. Laser Doppler Vibrometer is used to experimentally validate the numerical results of the wave propagation in the material. The presented numerical model is able to identify directivity patterns ...

COMSOL Analysis of Acoustic Streaming and Microparticle Acoustophoresis

H. Bruus[1], P.B. Muller[1], R. Barnkob[1], M.J.H. Jensen[2]
[1]Technical University of Denmark, Kongens Lyngby, Denmark
[2]COMSOL, Kongens Lyngby, Denmark

We have simulated the ultrasound-induced acoustophoretic motion of microparticles suspended in an aqueous solution. The full first-order thermoviscous acoustics equations have been implented on a rectangular microfluidic 2D domain excited with an ultrasound field tuned to resonance near 2 MHz. The micrometer-thin but crucial viscous boundary layers at the rigid walls have been fully resolved. The ...

Scale-up Design of Ultrasound Irradiator for Advanced Oxidation Process (AOP) Using COMSOL Multiphysics® Simulation

Z. Wei[1]
[1]The Ohio State University, Columbus, OH, USA

Ultrasound is a promising green technology for the advanced oxidation process (AOP) since it adds no chemicals to the treated water. In this paper, COMSOL Multiphysics® was used as a tool to design and characterize an ultrasound irradiator with multi-stepped configuration, which aims to overcome disadvantages of typical irradiators and to enhance contaminant removal in large-scale water ...
