Here you will find presentations given at COMSOL Conferences around the globe. The presentations explore the innovative research and products designed by your peers using COMSOL Multiphysics. Research topics span a wide array of industries and application areas, including the electrical, mechanical, fluid, and chemical disciplines. Use the Quick Search to find presentations pertaining to your application area.

Mie Scattering of Electromagnetic Waves

J. Crompton[1], S. Yushanov[1], K. Koppenhoefer[1]
[1]AltaSim Technologies, Columbus, OH, USA

The Mie solution to the scattering of electromagnetic waves by spherical particles has been examined using COMSOL Multiphysics®. The results assume elastic scattering only and do not include Brillouin or Raman scattering. The nature of the interaction has been considered for materials with three different properties: metallic, magnetic and dielectric. The solutions provide details of the ...

Numerical Study of Local Density of States in Photonic Crystal Waveguides

A. Javadi[1], P. Lodahl[1]
[1]Niels Bohr Institute, University of Copenhagen, Copenhagen, Denmark

In this contribution we study how a planar photonic crystal waveguide (PhCW), created by introducing a line defect in the photonic crystal, can modify the projected local density of states (LDOS) for a dipole emitter. We use the COMSOL Multiphysics® RF Module to carry out eigenvalue calculations studies on PhCW. When the dipole is in resonance with the waveguide mode, the enhancement Fp of ...

Optical and Electrical Modeling of Three Dimensional Dye Sensitized Solar Cells

P. Guo[1]
[1]Northwestern University, Evanston, IL, USA

Dye sensitized solar cells (DSSCs) have received tremendous attention as alternative photon harvesting devices. While the sintered TiO2 nanoparticle network attached with dye molecules achieves efficient photon absorption, the electrons have to diffuse through the long TiO2 network to reach the contact, resulting in a high electron density and thus increased recombination. Extensive research ...

Simulation of Optical Properties of the Si/SiO2/Al Interface  at the Rear of Industrially Fabricated Si Solar Cells

Y. Yang[1], and P. Altermatt[1,2]
[1]Institute for Solar Energy Research Hamelin (ISFH), Emmerthal, Germany
[2]Dep. Solar Energy Research, Inst. Solid-State Physics, Leibniz University of Hanover, Germany

The specular and diffuse reflection properties of sunlight at the rear surface of silicon solar cells with various degrees of roughness are computed by solving the Maxwell and material equations in two dimensions, using the COMSOL RF Module. The model is tested on planar Si/SiO2/air interfaces and planar Si/SiO2/Al interfaces. The simulations show that for wavelengths of 800 nm, (i) maximum ...

Implementation of the Perfectly Matched Layer to Determine the Quality Factor of Axisymmetric Resonators in COMSOL

M.I. Cheema, and A.G. Kirk
McGill University, Montreal, QC, Canada

Due to the inseparability of the wave equation, numerical methods are needed to develop an accurate electromagnetic model for various axisymmetric resonators such as micro-discs and micro-toroids. Our purpose is the implementation of a perfectly matched layer to determine the quality factor of axisymmetric resonators with high accuracy in COMSOL. We treated the perfectly matched layer as an ...

Towards Modelling Semiconductor Heterojunctions

R. Millett[1], J. Wheeldon[2], T. Hall[1], and H. Schriemer [1,2]
[1] Centre for Research in Photonics, School of Information Technology and Engineering, University of Ottawa, Canada
[2] Centre for Research in Photonics, Dept. of Physics, University of Ottawa, Canada

A 2D multiphysics model has been developed to simulate heterojunctions separating abruptly doped semiconductor layers of different dopant concentrations. Numerical results are presented for the case of nN, pN and PpN heterojunctions, and a general procedure for simulating multiple heterojunctions is described.

Effects of Forced Airflow Cooling on Laser Beam Heating of Volume Bragg Gratings

S. Kaim[1], B. Anderson[1], G. Venus[1], J. Lumeau[1], V. Smirnov[2], B. Zeldovich[1], L. Glebov[1]
[1]CREOL, The College of Optics and Photonics, University of Central Florida, Orlando, FL, USA
[2]OptiGrate Corp, Oviedo, FL, USA

Forced airflow cooling of a Volume Bragg Grating heated by a laser beam was investigated by means of simulation with COMSOL Multiphysics®. In addition to air cooling of unrestricted airflow, a case of airflow directed by limiting glass plates was investigated. A number of temperature distributions and thermal deformations were obtained in simulations for different rates of airflows. Simulations ...

Numerical Analysis of Perforated Microring Resonator Based Refractive Index Sensor

M. Gabalis[1], D. Urbonas[1], R. Petruskevicius[1]
[1]Institute of Physics of Center for Physical Sciences and Technology, Vilnius, Lithuania

In this work perforated microring resonator based refractive index sensor is presented. Numerical analysis of the microring using COMSOL Multiphysics® was performed. From transmission spectra sensitivity and quality factor of our proposed structure were evaluated. It was shown that perforated microring resonator exhibits higher sensitivity than ordinary microring resonator while also maintaining ...

Simulations of nanophotonic waveguides and devices using COMSOL Multiphysics

Z. Zheng
School of Electronic and Information Engineering, Beihang University, Beijing, China

Design and optimization of the nanophotonic devices are critical in realizing advanced photonic integrations in the future. COMSOL can be used for simulating various types of nanophotonic devices involving different materials and dimensions. This report talks about some recent work of Prof. Zheng’s team, including the simulation of dielectric photonic waveguides, optic fibers and surface ...

Surface Plasmon Resonance

J. Crompton[1], S. Yushanov[1], L.T. Gritter[1], K.C. Koppenhoefer[1]
[1]AltaSim Technologies, Columbus, OH, USA

The resonance conditions for surface plasmons are influenced by the type and amount of material on a surface. Full insight into surface plasmon resonance requires quantum mechanics considerations. However, it can be also described in terms of classical electromagnetic theory by considering electromagnetic wave reflection, transmission, and absorption for the multi-layer medium. The two commonly ...
