アプリケーションギャラリには電気, 構造, 音響, 流体, 熱および化学分野に関連する COMSOL Multiphysics® チュートリアルおよびデモアプリファイルが用意されています. これらの例はチュートリアルモデルまたはデモアプリファイルとそれに付随する手順をダウンロードすることにより独自のシミュレーション作業の開始点として使用できます.
クイック検索機能を使用して専門分野に関連するチュートリアルやアプリを検索します. MPHファイルをダウンロードするには, ログインするか, 有効な COMSOL ライセンスに関連付けられている COMSOL アクセスアカウントを作成します. ここで取り上げた例の多くは COMSOL Multiphysics® ソフトウェアに組み込まれ ファイルメニューから利用できるアプリケーションライブラリからもアクセスできることに注意してください.
磁歪変換は, ソナー, 音響機器, アクティブ振動, 位置制御, 燃料噴射システムに用いられます. この変換器は, 駆動コイルを囲む鋼製ハウジングを有しています. 磁歪材料はコア内に配置されており, 駆動コイルに電流を流すことで磁場が発生すると, コアがアクチュエーターとして機能します. 磁歪材料は磁場の影響下で自由ひずみを示します. この2次元軸対称モデルでは, 磁歪と磁場間の非線形関係を非線形構成関係を用いて実現しています. また, 現実的な磁気挙動を反映するために, 非線形 B-H 曲線も使用されています. ... 詳細を見る
This tutorial simulates a standard test and benchmark model for nonreflecting conditions and sponge layers for linearized Euler-like systems. It involves the propagation of a transient Gaussian pulse in a 2D uniform flow. The Convected Wave Equation, Time Explicit interface solves the ... 詳細を見る
Striking a drum excites a spectrum of vibration modes that together make up the instrument’s characteristic sound or acoustic signal. These vibration modes correspond to the eigenmodes, or eigenfunctions, of the drum’s membrane. Thus you can study this problem by solving eigenvalue ... 詳細を見る
This model shows how to compute the anchor loss limited quality factor of a diamond disc resonator. The resonator is anchored to the substrate by a polysilicon post and power is transmitted to the substrate through the post. A perfectly matched layer is used to represent the essentially ... 詳細を見る
潜水艦の主な防御力は, 作戦中に潜水艦を隠蔽し続ける能力にあります. 電波は海水に強く吸収されるため, 音響航法測距 (ソナー) は潜水艦探知に用いられる主要な方法の一つです. ソナーシステムは, 水中探査や漁業にも用いられています. 設計者は, 潜水艦の等価反射面積を最小化するために, 音波の反射方法を解析します. ターゲット強度 (TS) は, ソナーターゲットの面積を表す指標です. このチュートリアルでは, ベンチマークターゲットエコー強度シミュレーション (BeTTSi) を用いたベンチマーク潜水艦のTSを解析するための簡略化された手法を紹介します. ... 詳細を見る
A solidly-mounted resonator (SMR) is a piezoelectric MEMS resonator formed on top of an acoustic mirror stack deposited on a thick substrate. This tutorial shows how to simulate an SMR in 3D. In this example, the eigenmodes were computed with varying number of particles attached to the ... 詳細を見る
In acoustofluidics, acoustics is used to manipulate particles and fluids in microfluidic devices. This model demonstrates the phenomena of the inhomogeneous acoustic body force and how it can move a fluid with an inhomogeneous density due to a solute. The model is of a 2D rectangular ... 詳細を見る
The acoustic field in a model of an axially symmetric lined aero-engine duct, based on modal sound transmission, is analyzed. The source is generated by a single mode excitation at a boundary. Sources and nonreflecting conditions are applied using port boundary conditions. The model ... 詳細を見る
In this tutorial, the acoustic properties of a wax guard are analyzed. A wax guard is a small perforated mesh used to protect the receiver (the miniature loudspeaker in a hearing aid) used for receiver-in-the-ear (RITE) or receiver-in-canal (RIC) hearing aids. Because of the very small ... 詳細を見る
When a droplet is placed on a substrate on which surface acoustic waves (SAWs) are traveling, the energy of the SAWs is transferred into the droplet to form an acoustic field. The transferred energy is attenuated and generates a streaming flow. This type of streaming enables contactless ... 詳細を見る
