アプリケーションギャラリ

This example demonstrates how to set up the classical external-flow problem of solving for the high-speed, compressible, turbulent flow over the ONERA-M6 wing. The problem involves finding a steady-state solution of the flow field around the 3D, swept wing geometry, immersed in a ... 詳細を見る

Many applications involve simulating the electromagnetic behavior of relatively thin material in voluminous domains. To save computer memory and processing time, the thin materials can be treated differently by resolving them with 3D meshes. Here, the modeling domain is a box filled ... 詳細を見る

The purpose of the app is to demonstrate and simulate the use of cyclic voltammetry. You can vary the bulk concentration of both species, transport properties, kinetic parameters, as well as the cycling voltage window and scan rate. Cyclic voltammetry is a common analytical technique ... 詳細を見る

Recovery of precious metals in recycling of electronics, or extraction from ore, is usually performed through leaching of the metal into an aqueous phase. Precious metals require the use of an oxidant, and often, a complexant. In the case of gold, the cyanide anion (CN-) forms a soluble ... 詳細を見る

Power inductors are a central part of many low-frequency power applications. They are, for example, used in the switched power supply for the motherboard and all other components in a computer. Computer simulations are necessary in the design of such inductors. This model calculates the ... 詳細を見る

This tutorial model analyzes the propagation of seismic waves through Earth's internal structure. The model uses a 2D axisymmetric geometry to represent the material discontinuities and the variation of properties through the concentric layers of the earth. A simplified earthquake ... 詳細を見る

This example models the temperature profile in a liquid-cooled prismatic battery pack during a high-rate charge. The pack consists of 16 prismatic battery cells connected by busbars, placed on an aluminum plate containing four cooling channels. The battery pack is assumed to have two ... 詳細を見る

The electrostatically tunable parallel plate capacitor in this example is a typical component in various MEMS devices for radio frequencies that range between 300 MHz and 300 GHz. You can modify the distance between the two plates, as the applied voltage changes, through a spring ... 詳細を見る

When high-fidelity measurement microphones are calibrated, a pressure reciprocity calibration method is used. During calibration, two microphones are connected at each end of a closed cylindrical cavity. For the calibration procedure, it is important to understand the acoustic field ... 詳細を見る

潜水艦の主な防御力は, 作戦中に潜航を維持する能力にあります. 電波は海水に強く吸収されるため, 音響航法測距 (SONAR) は潜水艦探知に用いられる主要な方法の一つです. ソナーシステムは, 水中探査や漁業にも用いられています. 設計者は, 潜水艦の等価反射面積を最小化するために, 音波の反射方法を解析します. このチュートリアルでは, BeTTSi ベンチマーク潜水艦 (ベンチマークターゲットエコー強度シミュレーション) による散乱について考察します. このモデルでは, 圧力音響学の漸近散乱インターフェースの高周波近似を使用しています. この解析は高速で, ... 詳細を見る
