アプリケーションギャラリには電気, 構造, 音響, 流体, 熱および化学分野に関連する COMSOL Multiphysics® チュートリアルおよびデモアプリファイルが用意されています. これらの例はチュートリアルモデルまたはデモアプリファイルとそれに付随する手順をダウンロードすることにより独自のシミュレーション作業の開始点として使用できます.
クイック検索機能を使用して専門分野に関連するチュートリアルやアプリを検索します. MPHファイルをダウンロードするには, ログインするか, 有効な COMSOL ライセンスに関連付けられている COMSOL アクセスアカウントを作成します. ここで取り上げた例の多くは COMSOL Multiphysics® ソフトウェアに組み込まれ ファイルメニューから利用できるアプリケーションライブラリからもアクセスできることに注意してください.
This benchmark model compares the damping coefficients of perforated plates from computation results versus experimental data. The simulation includes 18 different geometric configurations. It uses the Bao's perforation model, which is built-in in the Thin Film Flow physics interface. ... 詳細を見る
This conceptual example shows how to calculate critical points in models with contact. The model consists of a block modeled with the Solid Mechanics interface pressing on an arch modeled with the Shell interface. The contact problem is solved using the augmented Lagrangian method. The ... 詳細を見る
A 180° Ring Hybrid (Rat-Race Coupler) is a four-port network with 180° phase difference between two ports. It is cheaper to manufacture this type of microstrip line component compared to a wave guide 180° hybrid junction, so called magic-T. The objective of this model is to compute the S ... 詳細を見る
A capacitor, in its simplest form, is a two terminal electrical device that stores electric energy when a voltage difference is applied across the terminals. The stored electric energy is proportional to the applied voltage squared and is quantified by the capacitance of the device. This ... 詳細を見る
This example calculates the spectral properties of a 3D optical ring resonator. The model demonstrates how to use parts from the Wave Optics Parts Library and how to setup the Field Continuity boundary condition at boundaries, where there is a jump in the predefined phase approximation. 詳細を見る
COMSOL Multiphysics は, マウスを数回クリックするだけで, 個々のフェースまたはドメインを簡単にメッシュ化できる対話型メッシュ作成環境を提供します. 各メッシュ作成操作はメッシュ作成シーケンスに追加されます. 最終的なメッシュは, メッシュ作成シーケンスのすべての操作を構築した結果です. この例では, メッシュ作成シーケンスを使用して, 異なる要素タイプで構成されるメッシュを作成する方法を示します. メッシュ操作を追加, 移動, 無効化, 削除する方法と, メッシュ作成シーケンスでサイズ機能を使用してメッシュを制御する方法を学習します. 詳細を見る
この例では, 低周波と中周波で一般的なダイナミックコーンタイプのスピーカードライバーをモデル化する方法を示します. 解析は周波数領域で実行されるため, ドライバーの線形動作が表されます. モデル解析には, 周波数の関数として, 総電気インピーダンスと公称駆動電圧での軸上の音圧レベルが含まれます. ドライバーの空間特性は, 指向性プロットで表されます. チュートリアルモデルは, 磁場インターフェースと音響構造相互作用マルチフィジックスインターフェースの組み合わせを使用して設定されます. 最初の解析では, ... 詳細を見る
This model shows how to simulate a capacitively actuated surface micromachined accelerometer, using the Electromechanics Interface. It is based on a case study from the book Microsystem Design by Stephen D. Senturia (Kluwer Academic Publishers, 5th Edition, 2003, pages 513-525). 詳細を見る
Consider an infinitely long steel cylinder resting on a flat aluminum foundation, where both structures are elastic. The cylinder is subjected to a point load along its top. The objective of this study is to find the contact pressure distribution and the length of contact between the ... 詳細を見る
Some conventional three-port power dividers are resistive power dividers and T-junction power dividers. Such dividers are either lossy or not matched to the system reference impedance at all ports. In addition, isolation between two coupled ports is not guaranteed. The Wilkinson power ... 詳細を見る
