アプリケーションギャラリには電気, 構造, 音響, 流体, 熱および化学分野に関連する COMSOL Multiphysics® チュートリアルおよびデモアプリファイルが用意されています. これらの例はチュートリアルモデルまたはデモアプリファイルとそれに付随する手順をダウンロードすることにより独自のシミュレーション作業の開始点として使用できます.
クイック検索機能を使用して専門分野に関連するチュートリアルやアプリを検索します. MPHファイルをダウンロードするには, ログインするか, 有効な COMSOL ライセンスに関連付けられている COMSOL Access アカウントを作成します. ここで取り上げた例の多くは COMSOL Multiphysics® ソフトウェアに組み込まれ ファイルメニューから利用できるアプリケーションライブラリからもアクセスできることに注意してください.
This model exemplifies the analysis of strong wind flow around a solar panel and the corresponding structural displacement due to the wind's load. The solar panel is located in an array of equally spaced identical panels, which allows for the assumption that the periodic flow conditions ... 詳細を見る
Metal hydride tanks offer safe hydrogen storage, thanks to their low reactivity, and a relatively high hydrogen density. When developing metal hydride hydrogen tank designs, modeling and simulation is useful for optimizing operating conditions, such as gas composition, pressure, and ... 詳細を見る
シリコンウェハーは, 時間の経過とともに放射状に移動するレーザーによって加熱されます. さらに, ウェハー自体もステージ上で回転します. レーザーからの入射熱流束は, 表面上の空間的に分散した熱源としてモデル化されます. ウェハーの過渡的な熱応答が表示されます. 加熱プロセス中のピーク温度, 平均温度, 最小温度, およびウェハー全体の温度変化が計算されます. 詳細を見る
A cascaded cavity filter provides much better bandpass filter performance compared to a single cavity. Out-of-band rejection improves dramatically using a cascaded design. This model uses three rectangular cavity filters coupled via slots. The calculated S-parameters show excellent out ... 詳細を見る
このチュートリアルでは, 高分子電解質膜 (PEM) 燃料電池における相互に関連した電気化学反応, 電荷および化学種の輸送, そして熱伝達をモデル化します. ガス流路については, 水素アノード側には直線状の流路を, 空気カソード側にはメッシュ構造を使用します. セルは, 別の流路を流れる冷却流体によって冷却されます. 上部境界と下部境界には周期的な温度境界条件を適用し, 積層セル構成をエミュレートします. このモデルには, 電気浸透輸送 (抵抗) とメンブレインを介した水の透過も含まれています. 詳細を見る
In this example, the mechanical impact of a golf club hitting a golf ball is studied. The contact between the two parts is modeled using a viscous penalty formulation to stabilize the dynamic event. To properly model the large deformation, the golf ball is defined using a hyperelastic ... 詳細を見る
This example shows the modeling of a resin transfer molding (RTM) process for a wind turbine blade using the Two-Phase Flow, Level Set, Brinkman Equations interface. Resin is injected into a preform consisting of different composites with different anisotropic permeabilities. 詳細を見る
潜水艦の主な防御力は, 作戦中に潜水艦を隠蔽し続ける能力にあります. 電波は海水に強く吸収されるため, 音響航法測距 (ソナー) は潜水艦探知に用いられる主要な方法の一つです. ソナーシステムは, 水中探査や漁業にも用いられています. 設計者は, 潜水艦の等価反射面積を最小化するために, 音波の反射方法を解析します. ターゲット強度 (TS) は, ソナーターゲットの面積を表す指標です. このチュートリアルでは, ベンチマークターゲットエコー強度シミュレーション (BeTTSi) を用いたベンチマーク潜水艦の TS を解析するための簡略化された手法を紹介します. ... 詳細を見る
This tutorial model solves for an inductively coupled plasma reactor with RF bias (also known as ICP/CCP reactors) in a mixture of argon/chlorine. The model computes the fluid flow and gas heating. Important aspects and strategies for modeling electronegative discharges are discussed. 詳細を見る
この研究では, コンピュータの電源ユニット (PSU) の熱挙動をシミュレートします. このような電子機器の筐体の多くには, 電子部品が過度の高温によって損傷するのを防ぐための冷却装置が備えられています. このモデルでは, 排気ファンと穴あきグリルによって筐体内に空気の流れが生じ, 内部の熱を冷却します. 詳細を見る
