アプリケーションギャラリ

This example demonstrates how to model phase transition by a moving boundary interface according to the Stefan problem. A square cavity containing both solid and liquid tin is submitted to a temperature difference between left and right boundaries. Fluid and solid parts are solved in ... 詳細を見る

The engine block of a car includes a cooling jacket to remove excess heat from combustion. The cooling jacket consists of open spaces in the cylinder block and the cylinder head. When the engine is running, a coolant fluid is pumped through the jacket to keep the engine from overheating. ... 詳細を見る

真空乾燥は, 製薬業界や食品業界で, 湿った粉末から水や有機溶媒を除去するために頻繁に用いられる化学プロセスです. 真空乾燥システムを設計する際, エンジニアは製品の品質を高く維持しながら乾燥時間を最小限に抑えることを目指します. このモデルは, Nutsche 式フィルタードライヤーにおける真空乾燥を調査します. Nutsche 式フィルタードライヤーは, 湿ったケーキが充填された円筒形のドラムで構成されています. ケーキの上部は低圧のヘッドスペースにさらされ, 側壁と底壁は加熱流体にさらされます. 非常に低い圧力と高温で動作させることで, 液体の蒸発速度が増加し, ... 詳細を見る

The magnets in an Interior Permanent Magnet (IPM) motor are embedded in the rotor core, where they form narrow regions known as bridges. The thickness of the magnetic bridge is an important parameter to consider in design, both from the electromagnetic and the mechanical perspectives. As ... 詳細を見る

This application shows how mass transfer out from a thin 3D domain can be approximated using a 2D component with the domain feature Out-of-Plane Flux. This feature is useful when the concentration gradient in the out-of-plane direction (along the thickness) is small, and decreasing the ... 詳細を見る

Composite materials are often used in structural applications, where the ability to tailor properties such as stiffness and strength make them attractive compared to traditional engineering materials. In addition to structural applications, composites are also used in applications where ... 詳細を見る

This model approximates 3D spherical transport using a 1D model. Many models of industrial-transport problems allow the assumption that the problem is spherically symmetric. This assumption is of great importance because it eliminates two space coordinates to result in a 1D problem that ... 詳細を見る

This example demonstrates how to plot the interference pattern from the combination of two rays with slightly different optical path length. A simple Michelson interferometer is used to achieve a change of optical path length by slightly moving one of the mirrors. 詳細を見る

This example shows how to model a load which varies in space and time. A series of load pulses travel along a beam which is supported at equal distances. For some combinations of the traveling speed of the load pulses and the spacing between them, it is possible to excite resonances in ... 詳細を見る

A homopolar generator is composed of an electrically conductive rotating disc placed in a uniform magnetic field that is perpendicular to the plane of rotation. The motion of the conductor through the static magnetic field induces Lorentz currents in the disc. By connecting the outside ... 詳細を見る
