This model studies the separation of flocculants from turbulent multiphase flow in a circular secondary clarifier. Shown here are the velocity field and volume fraction of the dispersed phase. A new interface in the COMSOL Multiphysics 3.4 Chemical Engineering Module makes it easy to model such mixtures. Courtesy of COMSOL, Inc. |
