アプリケーションギャラリには電気, 構造, 音響, 流体, 熱および化学分野に関連する COMSOL Multiphysics® チュートリアルおよびデモアプリファイルが用意されています. これらの例はチュートリアルモデルまたはデモアプリファイルとそれに付随する手順をダウンロードすることにより独自のシミュレーション作業の開始点として使用できます.
クイック検索機能を使用して専門分野に関連するチュートリアルやアプリを検索します. MPHファイルをダウンロードするには, ログインするか, 有効な COMSOL ライセンスに関連付けられている COMSOL アクセスアカウントを作成します. ここで取り上げた例の多くは COMSOL Multiphysics® ソフトウェアに組み込まれ ファイルメニューから利用できるアプリケーションライブラリからもアクセスできることに注意してください.
Diesel particulate filters (DPFs) are designed to remove and filter soot (diesel particles) from the exhaust of diesel engine vehicles. The filters in such systems are typically structured with long, air-filled channels surrounded by a porous medium that retains the soot. Although the ... 詳細を見る
Perforates are plates with a distribution of small perforations or holes. They are used in muffler systems, sound absorbing panels, and in many other places as liners, where it is important to control attenuation precisely. As the perforations become smaller and smaller, viscous and ... 詳細を見る
This model defines a zero-gap alkaline water electrolyzer, where oxygen and hydrogen gas are evolved in porous gas diffusion nickel felt electrodes, placed adjacent to a porous separator (diaphragm). The geometry defines a unit cell of an electrolyzer stack, in turn comprising two full ... 詳細を見る
Acoustic streaming, a steady flow induced by sound waves, has been used in biomedical and engineering industrial., Examples include enhancement of convective heat transfer, ultrasonic cleaning, localized micro-mixing, hemolysis of blood cells, and micropumps etc. The phenomenon is ... 詳細を見る
このチュートリアルシリーズでは, インポートしたサーフェスメッシュの操作方法を学習します. 3つの椎骨と2つの椎間板のSTLファイルをインポートする方法, 穴, 位置ずれしたメッシュ頂点, 交差要素を修復する方法を詳しく説明します. さらに, メッシュの結合と交差, サーフェスメッシュの再メッシュ, 生成された領域でのシミュレーション用の四面体メッシュの生成方法についても説明します. このチュートリアルシリーズでは, インポートした椎骨と椎間板のメッシュを, 3つの椎弓根スクリューと固定ロッドのパラメーター化されたジオメトリと組み合わせる方法についても説明します. ... 詳細を見る
The problem of a plane wave scattering off a cylinder-shaped object suggests the use of the 2D axisymmetric formulation. This can save computation time and reduce the memory usage compared to the model in 3D space. This example demonstrates the use of the built-in plane wave expansion ... 詳細を見る
This tutorial model shows how to model a microspeaker located in a smart phone including the radiation through and interaction with the acoustic port that connects to the exterior. The model demonstrates a linear frequency domain analysis as well as a nonlinear time domain analysis. A ... 詳細を見る
This example models a solid oxide electrolyzer cell wherein water vapor is reduced to form hydrogen gas on the cathode, and oxygen gas is evolved on the anode. The current distribution in the cell is coupled to the cathode mass transfer of hydrogen and water and momentum transport. Two ... 詳細を見る
This tutorial model demonstrates the use of the multiphysics coupling feature Thermal Connection, Layered Shell, Edges. In this model, three layered shells are connected to heat domains by edges at difference locations related to the heat domains. The results obtained with the Heat ... 詳細を見る
このチュートリアルでは, 高分子電解質膜 (PEM) 燃料電池における相互に関連した電気化学反応, 電荷および化学種の輸送, そして熱伝達をモデル化します. ガス流路については, 水素アノード側には直線状の流路を, 空気カソード側にはメッシュ構造を使用します. セルは, 別の流路を流れる冷却流体によって冷却されます. 上部境界と下部境界には周期的な温度境界条件を適用し, 積層セル構成をエミュレートします. このモデルには, 電気浸透輸送 (抵抗) とメンブレインを介した水の透過も含まれています. 詳細を見る
