This is a conceptual model illustrating how to couple fluid-structure interaction, heat transfer, and thermal expansion. A bimetallic strip in an air channel is heated so that it bends. After some time, an airflow with an inlet temperature which varies in time is introduced. As a ... 詳細を見る

Centrifugal pumps are used in various applications and can be found in many industries. The size of the pump in this model is typical for automotive applications. This model shows how to set up rotating machinery simulations using the frozen rotor approximation for modeling centrifugal ... 詳細を見る

This case shows how to simulate moisture transport in a homogeneous wall under isothermal conditions. With this assumption, an analytical solution can be calculated. The homogeneous layer is initialized in moisture balance. At the beginning of the simulation, the relative humidity of ... 詳細を見る

Tilted pad thrust bearings are used in rotating machineries with high thrust loading. The thrust load is transferred from a sliding part to a stationary part through hydrodynamic oil films. The tilted pad thrust bearing consists of a series of flat surfaces sliding over stationary tilted ... 詳細を見る

The purpose of this model is to visualize the electric potential in an electrochemical cell, for example a battery. This is done at OCV and during operation. In a battery, this would correspond to OCV, discharge, and recharge. The potential profile is explained both for cells with planar ... 詳細を見る

アルカリ水電解は, 水素ガスを生成するための確立された工業プロセスです. セル内では, 陰極で水素ガスが, 陽極で酸素ガスが生成されます. 電解液は水溶液であり, 発生したガスが泡状になると, 実効イオン伝導率が低下します. また, 発生したガスは, 電極反応がアクセス可能な表面積を減少させることから, セルの性能に悪影響を及ぼす可能性があります. この例では, ガス生成がアルカリ電解セルの性能に与える影響を調査します. 詳細を見る

晶析は化学産業において重要な分離プロセスです. 医薬品や工業用化学品の製造に用いられています. また, 資源回収においても, 廃棄物から有用な物質を分離する方法として活用できます. このモデルは, 離散化ポピュレーションバランス方程式を解き, 0次元および3次元 T 型ミキサーにおける硫酸バリウムの沈殿から結晶粒度分布を求めます. 詳細を見る

This is a model of an RF waveguide bend with a dielectric block inside. There are electromagnetic losses in the block as well as on the waveguide walls which cause the assembly to heat up over time. The material properties of the block are functions of temperature. The transient thermal ... 詳細を見る

In the semiconductor manufacturing process, photoresist coating is an important process and the thickness of the photoresist layer needs to be precisely controlled. Usually, the photoresist layer is thinned by spin coating. The specific principle is to use centrifugal force to throw ... 詳細を見る

This example describes how to simulate the self-lubricating phenomenon of a liquid lubricant in a journal bearing. A porous bushing is press-fitted to a bearing and saturated with a lubricant. It acts as a reservoir for the redistribution of the thin film of lubricant between regions of ... 詳細を見る
