Modeling and Simulation of High Sensitivity CMOS Pressure Sensor Using Free Boundary Circular Diaphragm Embedded on Ring Channel Shaped MOSFET - new
S. Joy, T. Tom
Rajagiri School of Engineering and Technology, Kochi, Kerala, India
Sensors have diverse applications ranging from the medical field to space exploration. They convert physical parameters such as temperature, pressure, humidity etc. into an electrical output. The discovery of piezoresistivity property of silicon and germanium led to miniaturization of pressure sensors. Improvement in the sensitivity is the major factor to be considered while designing pressure ...
V. Antonucci, M. Esposito, R. Marzella, and M. Giordano
Institute for Composite and Biomedical Materials, CNR, Portici, NA, Italy
Imast, Portici, NA, Italy
A quasi static indentation test on a laminate composite has been investigated numerically and experimentally. In particular, the test has been implemented by COMSOL Multiphysics® and optimizing the Finite Element and mesh. In addition, the numerical strain results have been validated by the comparison with the respective experimental deformation data that have been obtained by fiber Bragg ...
P. Olsson, F. Larsson, A. Khlopotin, S. Razanica
Chalmers University of Technology, Gothenburg, Sweden
In solid mechanics, there is considerable interest in achieving “invisibility”. The applications in mechanics include protection of structures and parts of structures from potentially harmful transient waves and steady state vibrations. A suggested large scale application is that protection against seismic waves from earthquakes could be achieved by using cloaking to re-route the waves around ...
M. Ding, J. Lin
MIT/WHOI Joint Program in Oceanography, Cambridge, MA, USA
Woods Hole Oceanographic Institution, Woods Hole, MA, USA
We used COMSOL Multiphysics 4.3 to simulate the 2D elastoplastic deformation and plastic strain in a wedge-shaped plate above a subducting interface. The modeling results reveal that a pair of conjugate normal faults would first appear in the thinner part of the plate. Subsequently, a second pair of conjugate thrust faults would form in the thicker part of the plate. The duration of the seamount ...
I. Gonin, M. Awida, T. Khabiboulline, V. Yakovlev
Fermilab, Batavia, IL, USA
Project X is a proposed proton accelerator complex at Fermilab. The CW LINAC is based on five types of resonators operating at three frequencies: half-wave, spoke, and elliptical. The low beam current for the CW operation of Project X requires cavities to operate at a high loaded Q and, thus, narrow bandwidth. Therefore, it requires optimal mechanical design of the cavities to minimize the ...
R. Haemers, F. Broekkamp, H. van Halewijn
Fontys University of Applied Physics, Eindhoven, The Netherlands
The hills of South-Limburg, the Netherlands, are crisscrossed with underground limestone mines. These "caves" are not equally stable, and can be dangerous. With COMSOL Multiphysics® a stability assessment has been made. The first study examines the full stress and displacement profile without excavation. In a second study the domains of the corridors are excluded, to represent the excavation ...
Binkowski, S., Fahlenkamp, H.
Universität Dortmund, FB Bio- und Chemieingenieurwesen, Lehrstuhl Umwelttechnik
Hohlfaser-Membranmodule können zur Trennung von Flüssigkeits- und Gasgemischen eingesetzt werden. Sie sind ähnlich aufgebaut wie Rohrbündel-Wärmetauscher. Im Gegensatz zu diesen sind die Hohlfasern in kommerziellen Modulen häufig nicht geordnet sondern ungeordnet gepackt. Dadurch ergeben sich analytisch schwer beschreibbare Geschwindigkeits- und Konzentrationsverteilungen im Mantelraum der ...
E. Gutierrez-Miravete, and J. Lavin
Rensselaer at Hartford, Hartford, CT, USA
UTC-Pratt & Whitney, East Hartford, CT, USA
Isogrid plate components are widely used in aerospace structures because of their greater stiffness to weight ratios compared with thicker plates of the same material. Isogrid plates consist of flat plates conjoined with thin ribs in specific geometric patterns. The purpose of this study was to investigate the applicability of COMSOL Multiphysics for the determination of buckling loads and modes ...
Electro-Thermo-Mechanical Finite Element Modeling to Investigate the Reliability of Automotive MOSFET Transistor
T. Azoui, P. Tounsi, and J.M. Dorkel
CNRS, LAAS, Toulouse, France
3D electro-thermo-mechanical finite element model of power vertical MOSFET used in the automotive industry is presented in this paper. The presented paper is a qualitative study of power device results from electro-thermo-mechanical simulation. This study particularly interested in the stress generated at the interface between the bonding wires and the source metallization to evaluate the ...
A. Chakraborty, A. Kundu, S. Chatterjee, and B. Gupta
West Bengal, India
This paper presents a novel design of single-bit RF MEMS phase shifter. The basic novelty introduced for phase shifter design in this case, is by scaling down of the lateral dimensions of the conventional RF MEMS shunt switch by 10 times. The Mechanical and Electromechanical analysis of the designed miniature RF MEMS fixed-fixed beam is performed using COMSOL Multiphysics v.3.5a as an FEM ...
