micro pattern on circle

Posted 2018/12/17 19:30 JST Structural & Acoustics, MEMS & Piezoelectric Devices 3 Replies

Usama Tahir
Send Private Message Flag post as spam

Please login with a confirmed email address before reporting spam

Hi i want to create micro rectangular pattern on circle circumference like the figure in the attached file, i need help regarding this.

Attachments:

3 Replies Last Post 2018/12/24 23:19 JST
Jeff Hiller COMSOL Employee

Please login with a confirmed email address before reporting spam

Posted: 6 years ago 2018/12/18 2:05 JST

Hello Usama,

The simplest is probably to use the Rotate feature with a range operator in the Rotation Angle field, see attached file.

Best,

Jeff

-------------------
Jeff Hiller
Hello Usama, The simplest is probably to use the Rotate feature with a range operator in the Rotation Angle field, see attached file. Best, Jeff

Attachments:

Usama Tahir
Send Private Message Flag post as spam

Please login with a confirmed email address before reporting spam

Posted: 6 years ago 2018/12/24 17:10 JST

Helloo Dear Jeff. This file is not opening in Comsol 5.3.1 version it need latest version can you please send me this file in the version i have Regards Usama

Helloo Dear Jeff. This file is not opening in Comsol 5.3.1 version it need latest version can you please send me this file in the version i have Regards Usama
Jeff Hiller COMSOL Employee

Please login with a confirmed email address before reporting spam

Posted: 6 years ago 2018/12/24 23:19 JST

I cannot offer to post in the Discussion Forum in older versions. Please consider updating to the current version.

Best,

Jeff

-------------------
Jeff Hiller
I cannot offer to post in the Discussion Forum in older versions. Please consider updating to the current version. Best, Jeff
