アプリケーションギャラリには電気, 構造, 音響, 流体, 熱および化学分野に関連する COMSOL Multiphysics® チュートリアルおよびデモアプリファイルが用意されています. これらの例はチュートリアルモデルまたはデモアプリファイルとそれに付随する手順をダウンロードすることにより独自のシミュレーション作業の開始点として使用できます.
クイック検索機能を使用して専門分野に関連するチュートリアルやアプリを検索します. MPHファイルをダウンロードするには, ログインするか, 有効な COMSOL ライセンスに関連付けられている COMSOL アクセスアカウントを作成します. ここで取り上げた例の多くは COMSOL Multiphysics® ソフトウェアに組み込まれ ファイルメニューから利用できるアプリケーションライブラリからもアクセスできることに注意してください.
磁歪変換は, ソナー, 音響機器, アクティブ振動, 位置制御, 燃料噴射システムに用いられます. この変換器は, 駆動コイルを囲む鋼製ハウジングを有しています. 磁歪材料はコア内に配置されており, 駆動コイルに電流を流すことで磁場が発生すると, コアがアクチュエーターとして機能します. 磁歪材料は磁場の影響下で自由ひずみを示します. この2次元軸対称モデルでは, 磁歪と磁場間の非線形関係を非線形構成関係を用いて実現しています. また, 現実的な磁気挙動を反映するために, 非線形 B-H 曲線も使用されています. ... 詳細を見る
The installation verification application can be used to help verify that your COMSOL Multiphysics® or COMSOL Server™ installation works as expected on your hardware platforms and operating systems. The app automatically loads and runs a suite of test models and compares the results with ... 詳細を見る
The S–N curve, also called the Wöhler curve, is one of the most popular methods for fatigue evaluation. The curve relates stress amplitude to the limiting fatigue life and can be obtained directly from a set of standard fatigue test. Many times our applications are subjected to ... 詳細を見る
計算性能の向上と新しい数値手法の開発により, 室内音響シミュレーションにおける波動ベースの技術の使用はここ数年で広まっています. 壁における現実的なインピーダンス条件を含めるという課題は, 従来は周波数領域で解決されてきました. 最近の研究では, データの部分分数表現を使用して, 時間領域モデルに周波数依存インピーダンスを実装することに重点が置かれています. このチュートリアルでは, 部分分数フィット関数を使用して周波数依存の壁インピーダンスデータの部分分数表現を取得する方法と, ... 詳細を見る
This model shows how to simulate a capacitively actuated surface micromachined accelerometer, using the Electromechanics Interface. It is based on a case study from the book Microsystem Design by Stephen D. Senturia (Kluwer Academic Publishers, 5th Edition, 2003, pages 513-525). 詳細を見る
Double-pipe heat exchangers, with their typical U-turn shape, are one of the simplest and cheapest type of heat exchangers used in the chemical process industry. This example studies the cooling of hot oil (130°C) by a cool oil (60°C) entering in counter-current. As the oils flow ... 詳細を見る
Portal Cranes are common when handling heavy loads. In this example, the Beam interface is used to compute the stresses in a portal crane designed for lifting 15 tons. Three load cases are considered: self weight, payload, and thermal expansion on a hot summer day. An internal hinge ... 詳細を見る
In this example, a lumped model of a vehicle suspension system having 11 degrees of freedom is analyzed. The Mass, Spring, and Damper nodes of the Lumped Mechanical System interface are used to model the wheels, including suspension system as well as the seats with a passenger. The ... 詳細を見る
This is a benchmark model for rigid body dynamics. This model simulates the dynamic behavior of "Andrew’s squeezing mechanism", which is force driven and requires a very small time scale. Various angles in the mechanism are compared with the results from the reference. 詳細を見る
