ナトリウムイオン電池 (SIB) は, リチウムイオン電池 (LIB) の代替として広く提案されています. SIB の化学反応では, 電解質の電荷輸送と電極反応における酸化還元反応に Li+ ではなく Na+ を使用します. Na+ は Li+ よりも豊富で, 製造時の環境負荷が小さいという利点があります. しかし, SIB は一般的に LIB よりもエネルギー密度が低いため, 主に定置用途において LIB の代替候補となります. SIB の化学反応は LIB の化学反応と多くの類似点があり, 電荷輸送, 物質輸送, 電極反応速度論, ... 詳細を見る

In this tutorial model, it is demonstrated how to incorporate a localized nonlinearity in a submodel. In this case, an initial elastic analysis reveals that a small region of a structure has stresses above the yield limit. To improve the results, an elastoplastic material model is added ... 詳細を見る

High Cycle Fatigue (HCF) of a spoke in a wheel rim is studied. As the wheel rotates, the stress histories in the structure will become nonproportional. The risk of fatigue is evaluated using the Findley criterion. 詳細を見る

During quenching of steel, austenite decomposes into phases such as ferrite, pearlite, bainite, and martensite. A common way to illustrate the phase transformation characteristics of a particular steel alloy is to use transformation diagrams. Two of the most commonly used diagram types ... 詳細を見る

Double-pipe heat exchangers, with their typical U-turn shape, are one of the simplest and cheapest type of heat exchangers used in the chemical process industry. This example studies the cooling of hot oil (130°C) by a cool oil (60°C) entering in counter-current. As the oils flow ... 詳細を見る

このモデルは, 流体の流れと共役伝熱のシミュレーションの入門として意図されています. このモデルでは, デバイスの周囲に空気ボックスを描画してこのボックス内の対流冷却をモデル化し, 自動面積計算を使用して境界上の総熱流束を設定し, データセットの選択を使用して結果を効率的に表示する方法を説明します. 詳細を見る

This example models galvanic corrosion between two different phases in a magnesium alloy for a representative cross-sectional microstructure configuration. The Phase Field interface is used here to model dissolution of a constituent phase leading to topological changes. The electrode ... 詳細を見る

This example models an oil reservoir with two horizontal wells. The reservoir contains two phases, water and oil. Oil is recovered by injecting water through the bottom well, so the oil production rate and the water-oil production ratio over time are computed. 詳細を見る

This model shows how to combine an electric circuit simulation with a finite element simulation. The finite element model is an inductor with a nonlinear magnetic core and 1000 turns, where the number of turns is modeled using a distributed current technique. The circuit is imported ... 詳細を見る

This model simulates the isotropic compression of naturally structured and artificially structured clays using the Modified Structured Cam-Clay (MSCC) material model. The aim of the example is to reproduce the compression behavior given in a benchmark for four structured clays. 詳細を見る
