アプリケーションギャラリには電気, 構造, 音響, 流体, 熱および化学分野に関連する COMSOL Multiphysics® チュートリアルおよびデモアプリファイルが用意されています. これらの例はチュートリアルモデルまたはデモアプリファイルとそれに付随する手順をダウンロードすることにより独自のシミュレーション作業の開始点として使用できます.
クイック検索機能を使用して専門分野に関連するチュートリアルやアプリを検索します. MPHファイルをダウンロードするには, ログインするか, 有効な COMSOL ライセンスに関連付けられている COMSOL アクセスアカウントを作成します. ここで取り上げた例の多くは COMSOL Multiphysics® ソフトウェアに組み込まれ ファイルメニューから利用できるアプリケーションライブラリからもアクセスできることに注意してください.
流体が材料やエネルギーの輸送に使用される場合, 流動する流体の速度を知ることは重要です. 流速を測定する飛行時間法または通過時間法では, 超音波信号をパイプ内の主流に伝達して, 非侵襲的に流速を測定します. 主流に対して角度を付けて信号を送信することにより, 超音波信号は主流の方向に移動する場合は音速よりも速く伝わり, 主流に逆らって移動する場合は音速よりも遅く伝わります. 2 つの方向の移動時間の差は, 主流の速度に比例して増加します. このタイプの流量計は, 特に産業環境で多くの用途があります. このチュートリアルモデルでは, COMSOL ... 詳細を見る
キャビティ上の流れと生成される音色のノイズは, バルブやその他のキャビティがある配管システムにおける典型的な流れノイズ源です. このチュートリアルモデルは, ダクトシステムにおけるキャビティ流れノイズの単純なケースを表しています. このモデルは, Lafon らの例に基づいて設定されています. このチュートリアルモデルは, 音響モジュールと CFD モジュールの機能を使用して, COMSOL Multiphysics® で流体誘起ノイズシミュレーションを実行する手順を示しています. LES 流れに使用されるメッシュ解像度は, ... 詳細を見る
This model demonstrates how to compute the acoustic properties of an acoustic liner with a grazing flow. The liner consists of eight resonators with thin slits. The background grazing flow is at Mach number 0.3. The sound pressure level above the liner is computed and can be compared to ... 詳細を見る
This model demonstrates the use of the Two-Phase Thin-Film Flow, Phase Field multiphysics coupling, which can be used to predict the evolution of an interface between two different, immiscible fluids in thin, narrow channels. The example here presents a free boundary lubrication ... 詳細を見る
This model of a two-story house can be used to examine a contaminant leak and the subsequent contaminant dispersion that occurs due to convection and diffusion. Airflow and recirculation within the home are dependent on vent placement, and flow velocity may also vary at each vent. ... 詳細を見る
An important and interesting phenomenon with supersonic flows are expansion fans, which take place when the flow encounters a convex or expansion corner. The direction of the flow changes smoothly across the fan, while the Mach number increases. This 2D example models an expansion fan ... 詳細を見る
FSI analysis of a sports car side door and side rear view mirror. The model is based on large eddy simulation analysis of a sports car. The flow field is used for a structural analysis of the side mirror and side door to estimate the flow-induced vibrations. 詳細を見る
This example illustrates multiphase flow modeling in an airlift loop reactor. The reactor is filled with water and air bubbles are injected at the bottom through two frits. Due to buoyancy, the bubbles rise, inducing a circulating motion of the liquid. The model specifically investigates ... 詳細を見る
Chemical mechanical polishing (CMP) is a crucial technique for surface planarization, widely used in semiconductor fabrication and optical device manufacturing. This model simulates the flow field within the CMP retaining ring and tracks the motion of abrasive particles carried by the ... 詳細を見る
