アプリケーションギャラリには電気, 構造, 音響, 流体, 熱および化学分野に関連する COMSOL Multiphysics® チュートリアルおよびデモアプリファイルが用意されています. これらの例はチュートリアルモデルまたはデモアプリファイルとそれに付随する手順をダウンロードすることにより独自のシミュレーション作業の開始点として使用できます.
クイック検索機能を使用して専門分野に関連するチュートリアルやアプリを検索します. MPHファイルをダウンロードするには, ログインするか, 有効な COMSOL ライセンスに関連付けられている COMSOL Access アカウントを作成します. ここで取り上げた例の多くは COMSOL Multiphysics® ソフトウェアに組み込まれ ファイルメニューから利用できるアプリケーションライブラリからもアクセスできることに注意してください.
A quadrupole mass filter (QMF) is a key component of a modern mass spectrometer. A QMF uses direct current (DC) and alternating current (AC) electric fields to analyze positive or negative ions by mass to charge ratio. A QMF consists of 4 parallel rods spaced equidistantly, the ratio of ... 詳細を見る
Tonpilz トランスデューサーは, 比較的低周波で高出力の音響放射に使用されます. これは, ソナー用途で広く使用されているトランスデューサー構成の1つです. このトランスデューサーは, 中央のボルトで接続されたヘッドマスとテールマスの間に積層された圧電セラミックリングで構成されています. この例では, ボルトの事前応力の影響を組み込む方法を示します. ボルトの形状は部品ライブラリからインポートされます. 周波数応答は, 変形, 応力, 放射電力, 音圧レベル, 送信電圧応答 (TVR) 曲線, 音波ビームの指向性指数 (DI) ... 詳細を見る
In this example, the structural integrity of a cylinder made by a fiber composite is assessed both at the macroscale and at the microscale level. Along with macroscale analyses, structural composites need microscale stress and failure analyses to identify the critical constituents in ... 詳細を見る
This model determines the reflection coefficient of plane acoustic waves, at different frequencies and at different angles of incidence, off a water-sediment interface. The ability of the Poroelasitc Waves interface to model the coupled acoustic and elastic wave in any porous substance ... 詳細を見る
内部または外部の短絡や過度の加熱などの不適切な使用により, 個々のバッテリセルが熱暴走状態になり, 大量の熱が発生する場合があります. 熱暴走中に隣接するセル間で十分な熱が伝達されると, 隣接するセルも熱暴走状態になります. 熱暴走がパック全体に広がると, 重大な安全上の危険が生じます. バッテリパックを設計する際には, 暴走の伝播を緩和するための対策を講じる必要があります. このチュートリアルでは, イベントベースの熱源を使用して, 24個の円筒形セルで構成されるパック内の熱伝達と, その結果生じる熱暴走の伝播をシミュレートします. 詳細を見る
This tutorial model explains how to extract lumped matrices by means of the Stationary Source Sweep study. The capacitance matrix of a five-terminal system is used to infer the position of a metallic object rather like real-world capacitive position sensors. The example illustrates the ... 詳細を見る
Electrochemical supercapacitors feature relatively higher energy densities than conventional capacitors. With several advantages, such as fast charging, long charge–discharge cycles, and broad operating temperature ranges, electrochemical supercapacitors have found wide applications in ... 詳細を見る
The Marangoni effect results in a slip velocity in the tangential direction on a fluid/fluid interface due to gradients in the surface tension coefficient. When the surface tension coefficient is constant, a two-fluid system may exist in static equilibrium. This is because the surface ... 詳細を見る
This model calculates the current and charge characteristics of a floating gate Electrically Erasable Programmable Read-Only Memory (EEPROM) device. A stationary study demonstrates the effects of varying the charge stored on the floating gate by computing Current-Voltage curves as a ... 詳細を見る
This tutorial model solves for an inductively coupled plasma reactor with RF bias (also known as ICP/CCP reactors) in a mixture of argon/chlorine. The model computes the fluid flow and gas heating. Important aspects and strategies for modeling electronegative discharges are discussed. 詳細を見る
