The model shows how to calibrate the probability distribution of the Young's modulus and Poisson ratio based on a tensile test. The test measures the tensile force and the radial displacement for different values of the prescribed displacement. The model is based on synthetic data ... 詳細を見る

This example shows how to make a simple model for a binary distillation process. A thermodynamics property package, available in the Chemical Reaction Engineering Module, is created to study the separation of a nonideal mixture of ethanol and water. The required equilibrium relationship ... 詳細を見る

This model demonstrates how to perform simulations of an absorbing bandstop color filter, based on a hexagonal array of holes in a thin aluminum layer. The structure is hexagonally periodic but this example also shows how to set the model up as rectangularly periodic. 詳細を見る

The model studies optimal material distribution in a hook, which is symmetric about the z plane and consists of a linear elastic material, structural steel. It is subjected to two distributed edge load cases: One at the tip of the hook and one along its lower inner curve. The geometry is ... 詳細を見る

次のモデルは, 流れてくる流体に対して直角に流路内に置かれた長い円筒を過ぎる非定常で非圧縮性の流れを調べます. 円筒は流れの中心からいくらかオフセットされており, 定常状態の対称的な流れを不安定にします. 周期的な流れのパターンが現れるのに必要なシミュレーション時間は予測が困難です. 重要な予測因子は, 円筒の直径に基づくレイノルズ数です. 値が 100 未満の低い場合, 流れは定常です. このシミュレーションでは, レイノルズ数は 100 に等しく, 発達したカルマン渦列が生じますが, 流れはまだ完全に乱流ではありません. 詳細を見る

This is a benchmark model for a plane stress problem. The accuracy of the computed stress concentration is evaluated, and a mesh convergence study is performed for different element types. 詳細を見る

A monopile foundation is a large-diameter structural element that can be used to support structures like offshore wind turbines. This application exemplifies how the cathodic protection of a monopile decreases over time as the sacrificial anodes dissolve. The model can be used to ... 詳細を見る

An isothermal single particle model formulation for a lithium-ion battery is presented in this work. The single particle model is a simplification of the 1D formulation for a lithium-ion battery along with a few assumptions. The model is typically valid for low-medium current scenarios. ... 詳細を見る

Steel structures immersed in seawater can be protected from corrosion through cathodic protection. This protection can be achieved by an impressed external current or by using sacrificial anodes. The use of sacrificial anodes is often preferred due to its simplicity. This example models ... 詳細を見る

This example solves the problem of finding the optimal thickness profile of a flywheel, so that the moment of inertia is maximized without increasing the mass or the maximum stress in the flywheel. 詳細を見る
