アプリケーションギャラリには電気, 構造, 音響, 流体, 熱および化学分野に関連する COMSOL Multiphysics® チュートリアルおよびデモアプリファイルが用意されています. これらの例はチュートリアルモデルまたはデモアプリファイルとそれに付随する手順をダウンロードすることにより独自のシミュレーション作業の開始点として使用できます.
クイック検索機能を使用して専門分野に関連するチュートリアルやアプリを検索します. MPHファイルをダウンロードするには, ログインするか, 有効な COMSOL ライセンスに関連付けられている COMSOL Access アカウントを作成します. ここで取り上げた例の多くは COMSOL Multiphysics® ソフトウェアに組み込まれ ファイルメニューから利用できるアプリケーションライブラリからもアクセスできることに注意してください.
The electrochemical cell shown in this model can be regarded as a unit cell of a larger wire-mesh electrode that is common in many industrial processes. One of the most important aspects in the design of electrochemical cells is the current density distributions in the electrolyte and ... 詳細を見る
This model shows how shape optimization can be used design the coils of an ICP reactor to obtain plasma uniformity. The reactor in study is a planar ICP with the coils distributed along the radial direction. The Optimization study step is used to find the best coil placement so that the ... 詳細を見る
This tutorial model solves for a one-dimensional capacitively coupled plasma reactor in a mixture of argon/oxygen. Important aspects and strategies for modeling electronegative discharges are discussed. 詳細を見る
The tonpilz (sound mushroom) piezoelectric transducer is a transducer for relatively low frequency, high power sound emission. The transducer consists of piezoceramic rings stacked between massive ends and pre-stressed by a central bolt. The tail and head mass lower the resonance ... 詳細を見る
Surface chemistry is often an overlooked aspect of reacting flow modeling. This tutorial model shows how surface reactions and species can be added to study processes like chemical vapor deposition (CVD). The tutorial then models silicon growth on a wafer. Initially, the example uses a ... 詳細を見る
This benchmark model simulates a GaAs nanowire using the self-consistent Schrödinger-Poisson theory to compute the electron density and the confining potential profiles. The predefined Schrödinger-Poisson multiphysics coupling feature is combined with the dedicated Schrödinger-Poisson ... 詳細を見る
Tonpilz トランスデューサーは, 比較的低周波で高出力の音響放射に使用されます. これは, ソナー用途で広く使用されているトランスデューサー構成の1つです. このトランスデューサーは, 中央のボルトで接続されたヘッドマスとテールマスの間に積層された圧電セラミックリングで構成されています. この例では, ボルトの事前応力の影響を組み込む方法を示します. ボルトの形状は部品ライブラリからインポートされます. 周波数応答は, 変形, 応力, 放射電力, 音圧レベル, 送信電圧応答 (TVR) 曲線, 音波ビームの指向性指数 (DI) ... 詳細を見る
この一連のモデルは, COMSOL Multiphysics® を使用して, 2D, 2.5D, およびエンドエフェクトを含む完全な3Dで高度な電気機械モデリングを行う方法を示しています. 現代の電気自動車でよく使用される永久磁石同期モーターの性能を調査します. モーターには, セグメント化された磁石が V 字型に埋め込まれた8つのローター極があります. 直線またはステップスキューのローターと直線またはスキューのステーターのさまざまな組み合わせが調査されています. ステーターには, 分散ヘアピン巻線を備えた 48 個のスロットがあります. 公称機械出力は, 5000 ... 詳細を見る
This tutorial model solves for an inductively coupled plasma reactor in a mixture of CF4/O2. The plasma transport, magnetic fields, fluid flow, and heat transfer are solved for fully self-consistently. The oxygen mole fraction of the reactor feed is parameterized. 詳細を見る
