アプリケーションギャラリには電気, 構造, 音響, 流体, 熱および化学分野に関連する COMSOL Multiphysics® チュートリアルおよびデモアプリファイルが用意されています. これらの例はチュートリアルモデルまたはデモアプリファイルとそれに付随する手順をダウンロードすることにより独自のシミュレーション作業の開始点として使用できます.
クイック検索機能を使用して専門分野に関連するチュートリアルやアプリを検索します. MPHファイルをダウンロードするには, ログインするか, 有効な COMSOL ライセンスに関連付けられている COMSOL Access アカウントを作成します. ここで取り上げた例の多くは COMSOL Multiphysics® ソフトウェアに組み込まれ ファイルメニューから利用できるアプリケーションライブラリからもアクセスできることに注意してください.
The miniaturization of electronics devices requires batteries with higher energy density and power. To increase the contact area between the electrodes and the solid electrolyte, 3D configurations such as the trench geometry are used. This example demonstrates how to model a solid-state ... 詳細を見る
These models illustrate some important topics when modeling buckling imperfection. The Euler 2 Buckling Imperfection model shows a simple case with a cantilever beam buckling under compression. Three different buckling modes are combined as initial imperfections. The other model, ... 詳細を見る
This example illustrates a linear buckling analysis conducted for a corrugated conical shell, utilizing a single sector of the geometry along with cyclic symmetry periodicity edge conditions. The results are compared to those using the full shell geometry. 詳細を見る
Gradient-based optimization is an efficient way of computing better values for many control variables. This example optimizes diameters of individual members in a truss structure such that the structure becomes stiffer without adding mass to the structure. The structure will be only be ... 詳細を見る
Beam theories are well-developed for slender structures with homogeneous materials and isotropic cross-sections. The traditional beam theories do no apply to beams made of different materials in the cross-section. Therefore, a homogenization-based numerical model is needed to compute ... 詳細を見る
The homogenized material properties of a composite are computed based on the temperature-dependent properties of matrix and fiber. The homogenized parameters are compared to the analytical values derived from the rule of mixtures. This is an extension of model https://www.comsol.com ... 詳細を見る
This model uses the Granular Flow and Membrane interfaces to simulate the packing of spherical grains in a flexible container, a procedure often found in the processing industry. In this example, grains are packed into a cubic container constructed of a thin polymer fabric. Two packing ... 詳細を見る
A highly simplified pedestrian bridge is for simplicity imagined to consists of a concrete slab on supported by three I-beams. The design is to be evaluated for peak acceleration due to walking. The model analyzes uncertainty in peak acceleration due to some material damping properties ... 詳細を見る
In this multibody dynamics model of a simple counterweight trebuchet, a parametric sweep is used to study throwing distance as function of the sling length. For more details on performing a multibody analysis of a counterweight trebuchet, see this blog post: What Is the Physics Behind a ... 詳細を見る
This is a demo model to show how to model connections in a mechanical system using Multibody Dynamics interface. In this model, pantograph mechanism is modeled. The purpose of this mechanism is to produce an identical, either enlarged or miniaturized, copy of an existing drawing. 詳細を見る
