Here you will find presentations given at COMSOL Conferences around the globe. The presentations explore the innovative research and products designed by your peers using COMSOL Multiphysics. Research topics span a wide array of industries and application areas, including the electrical, mechanical, fluid, and chemical disciplines. Use the Quick Search to find presentations pertaining to your application area.

Physical and FEM Simulation of Microprobe Insertion into Brain Tissue

A. Eed Olamat, U. Hofmann, B. Pohl, and N. Nkemasong
University of Lübeck, Institute for Signal Processing, Lübeck, Germany

In order to investigate the implantation of microprobes into brain tissue, we developed a finite-element and a physical model to replace real biological tissue for mechanical testing. Penetrating forces of a tungsten indenter into a layered structure was investigated with different indentation speeds. Numerical and physical model are in good correspondence to each other and reproduce measured ...

A Flexible Scheme For Numerical Homogenisation In Linear Elasticity

A. Gerisch[1], S. Tiburtius[1], Q. Grimal[2], and K. Raum[3]
[1]Technische Universität Darmstadt, Germany
[2]Université Pierre et Marie Curie Paris VI, France
[3]Charité-Universitätsmedizin Berlin, Germany

Musculoskeletal mineralised tissues (MMTs), like bone or tendon, are a prime example of naturally occuring, hierarchically structured material. They display a great variety in mechanical function but are all based on essentially the same building block: the mineralised collagen fibril (100 nanometer in diameter). This building block is arranged in various spatial structures across many length ...

Numerical Homogenization in Multi-scale Models of Musculoskeletal Mineralized Tissues

A. Gerisch[1], S. Tiburtius[1], Q. Grimal[2], and K. Raum[3]
[1]Technische Universität Darmstadt, Darmstadt, Germany
[2]Laboratoire d’Imagerie Paramétrique, UPMC, Paris, France
[3]Julius Wolff Institut & Berlin-Brandenburg School for Regenerative Therapies, Charité-Universitätsmedizin Berlin, Berlin, Germany

Musculoskeletal mineralized tissues (MMTs), e.g. bone, are hierarchical composite materials. Their effective elastic properties at different scales are of interest for computational studies of the MMT’s response to mechanical loading but also to realistically simulate implant osseointegration. We combine multi-scale and multi-modal experimental techniques with mathematical modelling of MMTs ...

Dynamic Simulation of Bone Morphogenetic Protein Patterning in a 3D Finite-Element Model of the Danio Rerio Embryo

D. Umulis, and S. Lee
Purdue University
West Lafayette, IN

Zebrafish development of the dorsoventral axis relies on the spatiotemporal distribution of Bone Morphogenetic Protein (BMP) signaling, which is regulated by numerous secreted molecules such as Tolloid, Sizzled, and Chordin. The rich dorsal/ventral patterning network must achieve both spatial precision in the patterning of downstream targets and confernspatial precision at distinct time points ...

A Study of the Acoustic Response of Carbon Fiber Reinforced Plastic Plates

J. O'Donnell, and G. McRobbie
University of the West of Scotland
Paisly, United Kingdom

This paper gives an introduction to a continuing study detailing the process and development of using both experimental and Finite Element Analysis to characterise the acoustic response of a Carbon Fiber Reinforced Plastic (CFRP) laminate plate provided by a guitar manufacturer. The results show that there is a strong correlation between both the experimental and simulated data which gives ...

Development of the Service Frame for SBS Tracker GEM and TENDIGEM Development

F. Noto[1], E. Cisbani[2], F. Librizzi[1], F. Mammoliti[3], C.M. Sutera[1]
[1]Istituto Nazionale Fisica Nucleare - Sezione di Catania, Catania, Italy; Dipartimento di Fisica ed Astronomia, Università di Catania, Catania, Italy
[2]Istituto Nazionale Fisica Nucleare - Sezione di Roma, Roma, Italy; Istituto Superiore di Sanità, Roma, Italy
[3]Istituto Nazionale Fisica Nucleare - Sezione di Catania, Catania, Italy; Dipartimento di Fisica ed Astronomia, Università di Catania, Catania, Italy

The Gas Electron Multiplier (GEM) technology has been proven to tolerate rate larger than 50 MHz/cm² without noticeable aging and to provide the sub-millimeter resolution on working chambers up to 45x45 cm² [1]. A new GEM tracker is under development for the upgrade of the SBS spectrometer in Hall A at Jefferson Lab. The chambers of the tracker have been designed in a modular way: each chamber ...

Finite Element Analysis of Defibrillation Current Density in Pregnant Women

A. Jeremic[1], E. Khosrowshahli[1]
[1]McMaster University, Hamilton, ON, Canada

Although resuscitation during pregnancy is relatively uncommon and rarely causes death, they have a particularly large impact in terms of the mortality of the unborn child and long-term effects on families and society as whole. In this paper, we present a new 3D finite element model of a pregnant female torso which accounts for presence of amniotic liquid and calculate current density ...

Simulating Organogenesis in COMSOL Multiphysics®: Cell-based Signaling Models

D. Iber[1], J. Vollmer[1], D. Menshykau[1]
[1]Department of Biosystems Science and Engineering, ETH Zurich, Basel, Switzerland

Most models of biological pattern formation are simulated on continuous domains even though cells are discrete objects that provide internal boundaries to the diffusion of regulatory components. In our previous papers on simulating organogenesis in COMSOL Multiphysics® (Germann et al COMSOL Multiphysics® Conf Procedings 2011; Menshykau and Iber, COMSOL Multiphysics® Conf Proceedings 2012) we ...

Improvements on Liquid Cyclotron Target Loading/Unloading System Using COMSOL Multiphysics®

F. Alrumayan[1], A. Alghaith[1], J. Schneider, [1], M. Ahmed [1], M. Al-Qahtani[1]
[1]King Faisal Specialist Hospital and Research Centre, Riyadh, Saudi Arabia

A 3D model was developed using COMSOL Multiphysics® to study the flow dynamics of the water inside the geometry of the [13N] Ammonia target for medical application . The image attached shows a 3D model of the target. A significant improvement was noted after modifying the geometry as suggested by the model and delivery time of radioactive solution was dramatically reduced. Water and aluminum ...

Optimization of a Rotor Shape for Spherical Actuator with Magnetically Levitating Rotor to Match Octupole Field Distribution

M. Sidz[1], R. Wawrzaszek[1], L. Rossini[2], A. Boletis[3], S. Mingard[3], K. Seweryn[1], E. Onillon[2], M. Strumik[1]
[1]Space Research Centre of PAS, Warsaw, Poland
[2]CSEM Centre Suisse d’Electronique et de Microtechnique SA, Neuchâtel, Switzerland
[3]Maxon Motor AG, Sachseln, Switzerland

The use of a reaction sphere as an actuator used by satellite Attitude Control System was proposed over twenty years ago. In principle this concept assumes the use of a single reaction sphere which can be accelerated in any direction instead of a set of reaction wheels. The solution discussed in this work has been proposed and patented by CSEM company. Contrary to conventional ball bearing ...
