Accelerated Corrosion Test of a Scratched Galvanized Steel Sample
Application ID: 130341
An established method for benchmarking the atmospheric corrosion resistance of materials is the use of accelerated corrosion tests (ACT) performed in climate chambers. The main purpose of the ACTs is to make reliable and fast predictions of the long time behavior. The tests expose samples to cyclic conditions during a few weeks. Elevated temperature, repeated drying and wetting together with salt addition are conditions that typically speed up corrosion and characterize ACTs. The samples can be of all shapes and sizes, in setups targeting crevice or galvanic corrosion, or with inflicted damage.
This example studies a galvanized steel sample with crossing scratches that fully penetrate the zinc coating and expose the underlying steel. The corrosion is simulated for a dummy ACT running for 7 days. The model solves for a thin liquid film that covers the sample surface. Local variations in pH, corrosion products, and coating deterioration are shown.

この model の例は, 通常次の製品を使用して構築されるこのタイプのアプリケーションを示しています.
ただし, これを完全に定義およびモデル化するには, 追加の製品が必要になる場合があります. さらに, この例は, 次の製品の組み合わせのコンポーネントを使用して定義およびモデル化することもできます.
- COMSOL Multiphysics® and
- either the バッテリデザインモジュール, 化学反応工学モジュール, 腐食解析モジュール, 電気化学モジュール, 電気めっきモジュール, or 燃料電池&電解槽モジュール
アプリケーションのモデリングに必要な COMSOL® 製品の組み合わせは, 境界条件, 材料特性, フィジックスインターフェース, パーツライブラリなど, いくつかの要因によって異なります. 特定の機能が複数の製品に共通している場合もあります. お客様のモデリングニーズに適した製品の組み合わせを決定するために, 製品仕様一覧 を確認し, 無償のトライアルライセンスをご利用ください. COMSOL セールスおよびサポートチームでは, この件に関するご質問にお答えしています.
