アプリケーションギャラリ

この例では, フェーズフィールド損傷モデルを用いて, 切欠き付き穿孔板の脆性破壊をモデル化します. 板の形状は, 実験データから得られた寸法と材料特性に基づき, 混合モード破壊が誘発されるように設定されています. この例では, この種の問題に対して効率的かつ安定したソルバー構成を設定する方法を示します. 詳細を見る

圧電トランスデューサーは, 電流を音圧場に変換するか, 逆に音場から電流を生成するために使用できます. これらのデバイスは, 空気中や液体中で音を発生させる必要がある用途に一般的に有用です. このような用途の例としては, フェーズドアレイマイク, 超音波装置, インクジェット液滴アクチュエーター, 創薬, ソナートランスデューサー, バイオイメージング, 音響バイオセラピューティクスなどが挙げられます. この例では, トランスデューサー内の圧電振動を, 空気や水などの流体中の音響圧力波と結合させる方法を示します. 結合して解く物理現象は, 圧電応力-ひずみ, 電場, ... 詳細を見る

In this conceptual example, the soft impact between two elastic rings is modeled using the Solid Mechanics interface. One of the rings is given an initial velocity to initiate the impact event. Both rings are unconstrained and not subjected to any external forces. Contact is modeled ... 詳細を見る

This example demonstrates how to model moisture transfer and induced swelling in a paperboard roll subject to varying ambient conditions. The material properties of the paperboard are anisotropic. 詳細を見る

Interfacial failure by delamination or debonding can be simulated with a Cohesive Zone Model (CZM). This example shows the implementation of a CZM with a bilinear traction-separation law. It is used to predict the mixed-mode softening onset and delamination propagation in a composite ... 詳細を見る

Microstrip filters can be fabricated directly on a printed circuit board (PCB) with a microstrip line going from the input to the output. Along the microstrip line there are a number of stubs of certain lengths and widths. The design of the filter involves choosing the impedance of the ... 詳細を見る

This example studies viscoplastic creep in solder joints under thermal loading using the Anand viscoplasticity model, which is suitable for large, isotropic, viscoplastic deformations in combination with small elastic deformations. The geometry includes two electronic components (chips) ... 詳細を見る

The dynamic response of a human body in any vibration environment can be predicted using this biomechanical model. In the automobile industry for instance, this model can be used in ride quality simulation and designing vibration isolators such as seats. In this example, a ... 詳細を見る

This model simulates the mechanism of a differential gear used in cars and other wheeled vehicles. A differential allows the outer drive wheel to rotate faster than the inner drive wheel during a turn. This is necessary when a vehicle turns in order to allow the wheel that is traveling ... 詳細を見る

This model analyzes an RF MEMS switch consisting of a thin micromechanical bridge suspended over a dielectric layer. A DC voltage greater than the pull-in voltage is applied across the switch, causing the bridge to collapse onto the dielectric layer with a resulting increase in the ... 詳細を見る
