Friction Between Contacting Rings

Application ID: 13645


This is a benchmark model involving stick-slip friction of a ring rolling inside another ring. The displacement of the inner ring is computed and compared to the analytical result. This model also shows how to tackle friction dominated contact problem.

This model example illustrates applications of this type that would nominally be built using the following products:

構造力学モジュール
